In arc modes, the Interactive Differential Pair router would create unevenly spaced differential pairs if, in the rules, clearance > diff pair gap. ( BC:19905)Īn exception would occur when placing full stack vias in a PCB library, then switching to the Layer Stack Manager. In some cases, the error "E3DError: DXGI_ERROR_DEVICE_REMOVED" would be encountered. ( BC:18335)Ĭlearances between polygon and track primitives were correct on the PCB, but incorrect in the generated Gerbers. When exporting to AutoCAD, internal system layer names were being used and not the layer names defined through the Layer Stack Manager. Improved interactive routing performance in the presence of complex layer stack regions. When using the new Variant Manager, there were some cases where the error "Dispatcher processing has been suspended" would be encountered after clicking on the value for the Description parameter.Īdded a Silkscreen Preparation tool to the PCB/PCBLib editors providing silkscreen clipping, automated movement of silkscreen text and automated clipping or movement of fills/regions. When generating ODB++ data, the pin data in the components file was incorrectly including the designator of the component, instead of just the pin number. The Dimmed Objects slider bar (View Options tab of View Configuration panel) was returning to the default position after closing and opening Altium Designer.

In some cases, the error "EOleException: The specified argument is outside the range of valid values" would be encountered. The error 'A given document's ID is invalid' was encountered when trying to add more than three Draftsman documents to a design project. In some cases, the EOleException "Object reference not set to an instance of an object" would be encountered. In some cases, the "System.ArgumentOutOfRangeException" would be encountered.īrought back the autosizing feature for ports, enabled by default for a fresh installation (with no imported preferences) and only for newly-placed port objects. For a summary of new features and subsequent improvements in Altium Designer 23, see New in Altium Designer.
